Line 6 AAF6740 Catalyst CX 100 100 Watt 1x12 Combo Amplifier

SKU: AAF6740

$679.00
RRP $799.99
SAVE $120.99
Share:
  • IN STORE
  • Out Of Stock
  • SUPPLIER
  • 5+ In Stock
  • (Orders dispatched in 1 to 3 business days from Supplier)



(Orders dispatched in 1 to 3 business days from Supplier)






Line 6 AAF6740 Catalyst CX 100 100 Watt 1x12 Combo Amplifier

Catalyst CX 100 is a 100-watt dual-channel 1x12 combo amplifier featuring 12 Amp Voicings derived from Helix. It performs like a traditional guitar amp—while providing the increased versatility of a modern amp.

Features:

  • CHANNEL SELECT - There are two channels that may be configured individually and their settings saved. Press the CH A or CH B button to select a channel. Press the Manual button to enter Manual mode, which is independent of the two channels, and use the controls as you would on a traditional amp.
  • GUITAR INPUT - Plug your guitar in here.
  • AMP SELECTOR & LED - There are two Amp Groups, each comprising six Line 6 Amp Voicings—and pressing the CH A and CH B buttons simultaneously switches between them. Turn the Selector to load an Amp Voicing within the currently selected Group.
  • RING - There are two Amp Groups, each comprising six Line 6 Amp Voicings—and pressing the CH A and CH B buttons simultaneously switches between them. Turn the Selector to load an Amp Voicing within the currently selected Group.
  • BOOST SWITCH & KNOB - Press the button to enable/disable the Boost feature. Use the Boost knob to adjust the boost level.
  • GAIN - Increases overdrive, distortion, and level.
  • BASS, MID, TREBLE - These controls operate just like those on a traditional amp. Settings are saved with individual presets, or apply globally when in Manual mode.
  • PRESENCE - Boosts specific upper-midrange and treble frequencies to make your tone more pronounced and “present.”
  • CH VOL - Controls the preset's channel volume.
  • EFFECT CONTROLS - Press the buttons to engage either or both of the effects. Use the Effect 1 and Effect 2 knobs to increase the amount of effect added to your tone. Various Delay, Modulation, Pitch/Filter, and Reverb effects may be assigned to these controls.
  • TAP/TUNER BUTTON - Tap in time with the music to set the tempo of delay and modulation effects. Press and hold to engage the Tuner.
  • MASTER VOLUME - Controls the overall volume of the amplifier and also the headphone volume.
  • POWER SWITCH - Turns the amplifier on and off.
  • AC IN - The included power cable is connected here.
  • OUTPUT POWER - Controls the overall power amp output. There are four options: Mute (for recording/headphone use), ½ watt (0.5 watts), 50% (half power), and 100% (full power).
  • USB-B PORT - Connect a desktop or mobile device to manage/edit presets, update firmware, or play and record audio. Provides 4-channel audio at 24-bit depth and 44.1kHz or 48kHz sample rates.
  • MIDI IN - Connect an external MIDI controller to remotely change presets, control assigned parameters, and more. (Catalyst CX 100 and 200.)
  • FOOTSWITCH - Connect an optional Line 6 LFS2 dual footswitch here to toggle between Channels A and B, and to switch Effect 1 on and off. The footswitches may also be reassigned to other functions using Catalyst Edit.
  • AUX IN - An auxiliary audio input for connecting external audio sources directly (unprocessed) to the amplifier’s power amplifier and speakers.
  • PHONES - Connect headphones here and use the Master volume control to adjust the level. The amplifier’s power amp and speakers are muted when headphones are connected.
  • FX LOOP - Connect external effects using standard 1/4" instrument cables.
  • MODE SWITCH - Controls the function of the FX Loop Return jack. Toggle to the left to engage the FX Loop. Toggle to the right to engage the Power Amp In.
  • GND-LIFT - Ground-lift switch for the XLR Direct Out(s).
  • DIRECT OUT - Connect an XLR cable to route line-level audio to a P.A. or other mixer, an audio interface, etc. This output is not affected by the Master volume control.
SKU AAF6740
Barcode # 614252343534
Brand Line 6
