- 61 keys (with velocity)
- SOUND GENERATOR
SuperNATURAL Acoustic Piano (EXSN01/03 Preload)
SuperNATURAL Electric Piano (EXSN02 Preload)
VTW Organ (Only ZONE2)
Various MODEL sound generators (Require adding EXM Series)
* ZEN-Core Tones and Model Tones can import and export.
* Backup file has compatibility with FANTOM-6/7/8, but it can read the enabled features only.
- EXZ Series
* The expansion are rewritable internal sound generator memory.
You can download data from the Roland Cloud and write it via a USB flash drive into the FANTOM's internal memory.
- 16 zones (Internal + External)
- 128 scenes x 4 bank
* The Scenes can import and export.
- 3,500 tones or greater
90 Drum kits or greater
- Tone Remain
- 8 zones
* When "Scene Remain Switch" enabled.
Tone Remain does not apply to VTW Organ sounds.
- Rating System: 4 steps (0-3)
- Tone Search/Scene Search
- Rating, Character
- Multi-Effects: 16 systems, 90 types
Part EQ: 16 systems
Drum Part COMP: 6 systems
Insertion Effect: 2 systems, 90 types (Serial/Parallel connection selectable)
TFX: 1 system, 90 types
Input MFX: 1 system, 90 types
Chorus: 9 types
Reverb: 7 types
Input Reverb: 7 types
Input EQ: 1 system
- Band: 13, 20, 32
Type: Mono, Stereo
Preset Setting: 10
User Setting: 20
- Scene Chain
- Chain: 16 Scenes x 32 Pages (Total 512 Scenes) per 1 Chain set
Marker: 36 (0-9, A-Z, a-z) per 1 Chain Set
- PATTERN SEQUENCER
- MIDI Tracks
- 8 (per each track)
- Pattern Length
- 64 measures
- Recording Method
- Realtime recording, Step recording, TR-REC
- Editing Method
- Piano roll edit (Touch Edit/Automation support), Microscope
- 1 (per Scene)
- File format
- Original, SMF export/import supported
* PAD Sampler trigger data can be recorded.
- SMF PLAYER
- SMF (Format 0/1)
- MIDI tracks
- Tempo range
- 5-300 BPM
- Transpose function
- -5-+6 semitone
- Track Mute
- Track Solo
- A/B loop function
* The pattern sequencer and SMF player can be used in each scene.
They cannot be used at the same time.
- SAMPLER - KEYBOARD MULTISAMPLE
- 16/24-bit linear, 44.1/48 kHz, WAV/AIFF import supported.
- Number of Samples
- Number of Multisamples
- Sampling Time
- The maximum is 2 minutes 44 second (1 Sample).
* A total of approximately 256 MB (Share with Expansion titles)
* Keyboard Multisample can import and export as ZEN-Core Tone.
- SAMPLER - PAD SAMPLER
- 16/24-bit linear, 44.1/48 kHz, WAV/AIFF import supported
- Maximum Polyphony
- Number of Samples
- 16 pads x 4 banks
- Sampling Time
- The maximum is 60 minutes (the equivalent of approximately 660 MB).
* A total of approximately 2 GB (including imported WAV files)
* When you use the PAD samples as KBD Wave, then you have to manipulation it.
- SAMPLER - INTERNAL STORAGE SPACE FOR FILES
- 2 GB
- Rhythm Pattern
- Chord Memory
- Motional Pad
- PAD Mode
- Sample Pad,Note Pad,Partial Sw/Sel,DAW Control,Zone Mute,Zone Solo,Kbd Sw Group,Rhythm Pattern,Pattern,Variation Play,Group Play
- AIRA LINK
- * When connect to MX-1
- Pitch Bend/Modulation lever *1
Assignable Switch x 2 (S1/S2)
Control knob x 8
Slider x 8
Wheel x 2 *1
Function knob x 6
Sound Modified knob x 2 *1
4 x 4 Pad
*1: 1,024 step editing support
It can be use with Cutoff, Resonance.
- Graphic Type, 5.5" (1,280 x 720 dots), backlite LCD (Color/Touch screen, Screensaver, Wallpaper support)
- Headphones jack: Stereo 1/4-inch phone type
MAIN OUT jacks (L/MONO, R) (1/4-inch TRS type)
SUB OUT jacks (L/MONO, R) (1/4-inch phone type)
SUB OUT STEREO (PHONES) jacks: Stereo miniature phone type PHONES Support
Mic Input jacks: 1/4 inch TRS type
Line Input jacks: (L/MONO,R) (1/4 inch phone type)
FOOT PEDAL jacks(HOLD, CTRL1, CTRL2)
MIDI connectors (IN, OUT)
USB MEMORY port
USB COMPUTER port (AUDIO/MIDI)
External Device Port: A Roland A-49 or an A-PRO series MIDI Controller can be connected. * Operation is not guaranteed if a generic MIDI device is connected.
- Audio Interface
- Max 24 bit/96 KHz
Record 16 Stereo Channel
Playback 2 Stereo Channel
- External Memory
- USB Flash drive (sold separately)
- Power Supply
- AC Adaptor
- Power Consumption
- 1,300 mAh
- Owner's Manual
- Options (sold separately)
- Keyboard Stand:
KS-10Z, KS-12, KS-20X
Pedal Switch: DP series, RPU-3
Expression Pedal: EV-5
USB Flash drive
- SIZE AND WEIGHT
- 1,006 mm
- 323 mm
- 95 mm
- 6.0 kg
13 lbs 4 oz
